Brackets to connect hip trusses to girders
Uses
The Pryda Hip Support Bracket has been developed to overcome a common timber connection headache. There has been no easy and economical solution to joining a hip to the bottom chord of a girder truss at the same junction as another supported girder truss.
Features
The HSB is simply screw fixed over the left or right hand flange of a TB35 or TB45 truss boot. The hip truss or rafter is then screwed onto the bracket from underneath.
Application
For application and design capacity information, refer to the Pryda Hangers & Truss Boot Guide.
Pryda Hip Support Bracket 3.0mm
| Product Code | Size |
|---|---|
| HSB | 75 x 68 x 100 x 3mm |
